Our media service about our environmental activities provides appropriate images arranged in galleries.
If used in publications, please always give copyright credit to: © WIEGEL Verwaltung GmbH & Co KG.
For high-resolution images, please contact: medienservicewiegelde.

Gallery 1: Galvanizing line
Enclosure of a galvanizing kettle
Suction nozzle in the top section of the enclosure
Suction nozzle in the top section of the enclosure
The fan is downstream of the filter unit
Exhaust air filter with collecting bin for filter dust
Suction nozzle in the top section of the enclosure
The powerful fan has a volume flow rate of up to 20,000 cbm per hour
Measuring the pressure difference to determine the dust load in the filter
Supply and return flow to the heat exchanger in the flue gas flow
Gallery 2: Pre-treatment line
Scrubber tower
Scrubber tower
Exhaust air fan in the pre-treatment line
The purified exhaust air leaves the pre-treatment line scrubber tower through the exhaust air pipe
Scrubber tower controller
Storage tank for fresh acid
View of the top of the fresh acid tanks
Connector and filler valve for refilling the acid tanks
In the collecting basin: looking between two pre-treatment baths
Gallery 3: Furnace controller
Looking through an inspection window in the combustion chamber
Temperature probes measure the temperature of the molten zinc bath precisely
Control panel of the furnace controller
The temperature in the zinc kettle can be controlled with a precision of +/- 0.1 °C
Control panel
Gallery 4: Occupational health and safety
Detailed work instructions are accessible for every employee at any time
Personal protective equipment is mandatory
Signal and warning sign panel in the pre-treatment line
Gloves and a visor must be worn when working at the zinc kettle
Emergency shower
Gallery 5: Miscellaneous
Control panel for technical modules
High efficiency LED hall lighting
We are proud of our EMAS validation
Zinc is recyclable and is thus a sustainable raw materia
Hot-dip galvanization is a so-called hot dipping process
Hot-dip galvanized workpieces are particularly well protected against corrosion
